Description ACA LEAKAGE TESTER Model : DL-6054 FEATURES * High precision AC mA measurement, it is useful for AC mA leakage current measurement. * Measure AC mA on the inductive conductor. * Miniature type, easy to carry out & operation. * High precision for low ACA leakage current measurement. * Built-in DATA HOLD function. * Crystal time base, high quality. * LCD display allows clear readout-out even at high ambient light level. * LSI circuit provides high reliability and durability. * Overload protection circuit is provided for all range. * Design to meet IEC 1010 safety requirement. * Compact, light weight and excellent operation. SPECIFICATIONS Display 13 mm ( 0.5″ ) LCD, 3 1/2 digits. Max. indication 1999. Measurement & 200 AC mA x 0.1 mA Resolution 20 ACA x 0.01 A 200 ACA x 0.1 A Data Hold Available to hold the measuring values on the display. Accuracy ± ( 1.2 % 5 d ) (23 5 蚓) * Specification be tested on sine wave 50, 60 Hz. Time Base Quartz crystal, 32768 Hz. Overload Circuit 300 ACA max. ( within 1 minute for 20A, Protection 200A range ). Zero adjustment Automatic adjustment. Over input Display shows ‘1’. Sampling Time Approx. 0.4 second. Operating Temp. 0 to 50 ℃ ( 32 to 122 ℉ ). Operating Humidity Less than 80% RH. Battery 006P DC 9V battery. Power Consumption Approx. DC 1.2 mA. Weight 200 g/0.44 LB ( including battery ). Dimension HWD 180 x 47 x 35 mm. 7.1 x 1.9 x 1.4 inch. Conductor Size 19 mm Dia. Accessories Operation manual…………………………………… 1 PC. Included Carrying case………………………………………. 1 PC. * Appearance and specifications listed in this brochure are subject to change without notice. DL6054
