Description One tachometer, multiple measurements: The testo 470 tachometer carries out rpm measurements on motors, shafts, fans, etc., but that’s not all. With this handy instrument, you can also determine speeds and lengths (e.g. of conveyor belts and rotors). Multiple functions in one tachometer In the case of optical rpm measurement, you can use the testo 470 tachometer to record how fast a rotating object rotates. Thus, for example, you can check whether motors, shafts and fans are functioning correctly in order to spot any impending defects due to overload at an early stage. For rpm measurement, simply stick a reflective marker on the measurement object and aim the visible red beam at the reflective marker. The measurement can then start (at a distance of up to 600 mm between tachometer and measurement object). The tachometer is easy to operate using one hand. However, the testo 470 tachometer not only provides the functions of an optical tachometer, it also functions as a mechanical tachometer: Attach the adapter for the probe tip and measure the rpm mechanically. Attach the wheel to also measure speeds and lengths of rotors/conveyor belts. You get the testo 470 tachometer in a transport case with practical accessories (reflective markers, softcase, etc.). Delivery Scope testo 470 tachometer with softcase, reflective markers, adapter, probe tip, wheels 0.1 m and 6″, batteries, transport case and calibration protocol. Technical data rpm – Optical Measuring range 1 to 99999 rpm Accuracy ±0.02 % of mv Resolution 0.1 rpm (100 to 999.9 rpm) 0.01 rpm (1 to 99.99 rpm) 1 rpm (1000 to 99999 rpm) rpm – Mechanical Measuring range 0.1 to 19999 rpm Accuracy ±0.2 % of mv General technical data Display type LCD (Liquid Crystal Display) Display size one-line Display function 5 digit LCD display
