Description FEATURES * Sensor used the exclusive photo diode & color * Built-in low battery indicator. correction filter, spectrum meet C. I. E. photopic. * LSI-circuit use provides high reliability and * Sensor COS correction factor meet standard. durability. * Separate LIGHT SENSOR allows user take * LCD display provides low power consumption. measurements of an optimum position. * Compact, light-weight, and excellent operation. * Precise and easy readout, wide range. * LCD display can clearly read out even of high * High accuracy in measuring ambient light. GENERAL SPECIFICATIONS Display 13 mm ( 0.5″ ) LCD. Power Approx. DC 2 mA. Measurement Lux, Ft-candle, Consumption Data hold, Analog output. Output Analog output. Ranges Lux : Operating Temp. 0 to 50℃ ( 32 to 12℉ ). 0 to 50,000 Lux, 3 ranges. Operating Less than 80% R.H. Ft-candle : Humidity 0 to 5,000 Ft-candle, 3 ranges. Dimension Main Instrument : Zero adjustment Internal adjustment . 163x70x30 mm(6.4×2.8×1.2 inch ) Over-input Indication of ” 1 “. Sensor probe: Sampling time Approx. 0.4 second. 82x55x7 mm ( 3.2×2.2×0.3 inch ). Sensor structure The exclusive photo diode & Weight 220g ( 0.52 LB ) with batteries. color correction filter. Accessories Instruction manual…………1 PC. Power Supply DC 9V battery. 006P, Included MN1604 ( PP3 ) or equivalent. ELECTRICAL SPECIFICATIONS (23 ± 5℃) Range Resolution Accuracy Range Resolution Accuracy 2,000 Lux 1 Lux ± ( 5 % 2 d ) 200 Ft-candle 0.1 Ft-candle ± ( 5 % 2 d ) 20,000 Lux 10 Lux ± ( 5 % 2 d ) 2000 Ft-candle 1 Ft-candle ± ( 5 % 2 d ) 50,000 Lux 100 Lux ± ( 5 % 2 d ) 5000 Ft-candle 10 Ft-candle ± ( 5 % 2 d ) ANALOG OUTPUT 0.1 mV/1 digit, Max. 200.0 mV. * Appearance and specifications listed in this brochure are subject to change without notice.
