Description FEATURES * 2 in 1, one meter included ” type k thermometer ” & Operating 0 to 50 ( ℃ ℃ 32 ℉ to 122 ℉ ). ” type k thermocouple calibrator “. Temperature * Precision calibrator for type k thermometer, calibrating Operating Less than 80% RH. process devices and measuring process signals. Humidity * Wide range : -199℃ to 1230℃ ( -325℉ to 2246℉ ). Power Supply 006P DC 9V, MN1604/PP3 battery or * Microprocessor circuit assures high accuracy and equivalent. provides special functions and features. Heavy duty or Alkaline type. * Build in temperature linearity compensation circuit, Power Approx. DC 9 mA. high precision. Current * ℃ & ℉ select & data hold function for the temperature Weight 280 g/0.62 LB ( included battery ). measurement. Size 185 x 78 x 38 mm ( 7.3 x 3.0 x 1.5 inch ). * ℃ & ℉ select by the front button for the temperature Accessories Instruction Manual ………………………. 1 PC. calibrator. Included Dual type k plug cable, DUK-02…….1 PC. * Thermocouple sensor for Temp. measurement, fast Optional * Temperature probe, TP-01, TP-02A, response time. Accessories TP-03, TP-04. * RS 232 PC serial computer interface. ( Please ref. * Carrying case, CA-03, CA-04. * Temp. measuring input to meet any standard type K page 9 ) * Software, SW-U801-WIN. ( NiCr-NiAl ) probe. * RS232 cable, UPCB-01. * Fitted with standard type K input measuring socket. * USB cable, USB-01. * Super large LCD display, easy reading. * Operates from 006P DC 9V battery. ELECTRICAL SPECIFICATIONS (23± 5 ℃) * Used the durable, long-lasting components, including a strong, light weight ABS-plastic housing case. Type K thermocouple Calibrator GENERAL SPECIFICATIONS Calibrator Range Resolution Accuracy Circuit Custom one-chip of microprocessor LSI with -199.9 ℃ to -100.1 ℃ 0.1 ℃ ± (1 % 1 ℃) thermocouple linearity correction circuit. ℃ -100.0 ℃ to 999.9 ℃ 0.1 ℃ ± (0.5 % 1 ℃) Display 14.8 mm (0.58″) digit size. Super large LCD 1000 ℃ to 1230 ℃ 1 ℃ display with annunciator. -327 ℉ to -200 ℉ 1 ℉ ± (1 % 2 ℉) Function 2 in 1 : -199.9 ℉ to -148.1 ℉ 0.1 ℉ Type k thermometer, ℉ -148.0 ℉ to 999.9 ℉ 0.1 ℉ ± (0.5 % 2 ℉) Type k thermocouple calibrator. 1000 ℉ to 2246 ℉ 1 ℉ Range Measure : -199.9℃ to 1230℃/ – 327℉ to 2246℉. Thermometer, measure Calibrator -199.9℃ to 1230℃/ – 327℉ to 2246℉. Thermometer Range Resolution Accuracy Polarity ‘ – ‘ indicates negative polarity. -199.9 ℃ to -100.1 ℃ 0.1 ℃ ± (1 % 1 ℃) Thermometer Sensor Thermocouple K ℃ -100.0 ℃ to 999.9 ℃ 0.1 ℃ ± (0.5 % 1 ℃) Type ( NiCr-NiAl ). 1000 ℃ to 1230 ℃ 1 ℃ Input 10 Mega ohm. -327 ℉ to -200 ℉ 1 ℉ ± (1 % 2 ℉) Impedance -199.9 ℉ to -148.1 ℉ 0.1 ℉ Sampling Approx. 1 second. ℉ -148.0 ℉ to 999.9 ℉ 0.1 ℉ ± (0.5 % 2 ℉) Data Output RS 232 PC serial computer interface. 1000 ℉ to 2246 ℉ 1 ℉ Over input Indication of ” “. The accuracy specification of thermometer applies only to indication the instrument itself and allowance must be made for limits of error permitted in thermocouple.
