Description Experience fast and easy inspections on the go with Fluke iSee™ Mobile Thermal Camera, weighing just 22g. It takes only a second to start using. The wide temperature measurement range, up to 550°C (1022°F), makes it suitable for various applications, including inspecting electrical cabinets, identifying HVAC issues, and installing underfloor heating. Fluke iSee boasts professional-grade image quality, comparable to high-end thermal cameras, with a 256 x 192 pixel thermal resolution and smooth video recording at a 25 Hz frame rate. Additionally, our software offers comprehensive spot, line, and area temperature analysis for precise diagnostics. Detailed image quality comparable to professional thermal imagers 256 x 192 pixels, detailed image quality -10 to 550 °C (14 to 1022 °F) range, covering wide applications 50 mk (0.05 °C) thermal sensitivity for fine screening ± 2% or ± 2 °C (3.6 °F) accuracy, reliable and stable 25 Hz frame rate, smooth video without lag More than 10 standard and custom color palettes to achieve a variety of personalized images Full temperature range analysis Real-time high and low-temperature capture, without missing any details Adjustable emissivity to cope with different materials Comprehensive temperature analysis for spot, line and area, professional-grade thermal imaging software Real-time temperature alarm, timely response, and handling Unattended automatic time-lapse photography Infrared and visible light image comparison for locating, comparing, and archiving Real-time image sharing, communication without barriers Real-time image and video sharing and management, fast and efficient communication It is easy to add image annotations, and communication without barriers Small and portable, it takes a second to get started Compact design as light as 22 g (0.78 oz), perfect for your mobile phone size The iSeeTM is made of high-quality aluminum material for the airway, with uniquely treated and laser-etched surface 1-meter drop test, IP54 ingress protection, Fluke durability Optimized Fluke iSeeTM application interfaces and menus with professional operating experience make it easy to access all functions TC01A TC01B Performance Specifications IR resolution 256 x 192 Pixel size 12 μm Temperature range -10 °C to 550 °C/14 °F to 1022 °F -20 °C to 550 °C/-4 °F to 1022 °F Temperature accuracy ± 2 % of rdg or ± 2 °C/3.6 °F, whichever is greater (@ 23 °C ± 5°C/73.4 °F ± 9 °F ambient temperature) Temperature measurement distance 0.25 m to 5 m (* -20 ℃/-4 °F to 10 ℃/50 °F, only for 0.25 m to 3 m) Frame rate 25 Hz Warm-up time 1 minute Focal length Fixed focal length: 3.2 mm Shutter mode Internal Thermal sensitivity (NETD) 50 mK Spectral range 8 to 14 μm Field of view (H x V) 56° x 42° Spatial resolution 3.81 mrad General Specifications USB interface Type-C Lightning Operating temperature 0 ℃ to 40 ℃/32 °F to 104 °F Storage temperature -30 ℃ to 60 ℃/–22 °F to 140 °F Operating humidity 10 % to 90 % RH, non-condensing Power consumption 350 mW (Typical) 200 mW (Typical) Drop test 1 m/3.3 ft Ingress protection IEC 60529: IP54 (with the protective cover for Type C) IEC 60529: IP56 Operating altitude 2 000 m/6 562 ft Storage altitude 12 000 m/39 370 ft Dimensions (L x W x H) 60 x 33.5 x 11.2 mm/2.36 x 1.32 x 0.44 in EMC Environment International IEC 61326-1: Electromagnetic environment for portable equipments CISPR 11: Group 1, Class A Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself. Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply net- work that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances. Caution: This equipment is not intended for use in residential environments and may not provide adequate protection to radio reception in such environments.
